In this tutorial, we’ll lock down a Spring Boot application using OAuth2 as our Authorization Server and JWTs for stateless authentication. You’ll configure an auth server, a resource server, and a web client that executes the Authorization Code flow—with no XML, just Java and YAML.

Why OAuth2 + JWT?

🔒 Standardized flows (authorization code, client credentials)
🆓 Stateless tokens that carry user claims and can be verified without a central session store
⚖️ Scalability—each service validates tokens locally

Prerequisites

Java 17+
Maven or Gradle
Basic Spring Boot familiarity
cURL or Postman for testing

1. Add Dependencies

<!-- pom.xml -->
<dependencies>
  <!-- Spring Web -->
  <dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-web</artifactId>
  </dependency>

  <!-- OAuth2 Resource Server -->
  <dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-oauth2-resource-server</artifactId>
  </dependency>

  <!-- Spring Authorization Server -->
  <dependency>
    <groupId>org.springframework.security</groupId>
    <artifactId>spring-security-oauth2-authorization-server</artifactId>
    <version>0.4.0</version>
  </dependency>

  <!-- JWT support -->
  <dependency>
    <groupId>com.nimbusds</groupId>
    <artifactId>nimbus-jose-jwt</artifactId>
  </dependency>
</dependencies>

2. Set Up the Authorization Server

Create AuthServerConfig.java under your auth-server module:

@Configuration(proxyBeanMethods = false)
public class AuthServerConfig {

    @Bean
    public SecurityFilterChain authSecurityFilterChain(HttpSecurity http) throws Exception {
        OAuth2AuthorizationServerConfiguration.applyDefaultSecurity(http);
        return http
          .formLogin(Customizer.withDefaults())
          .build();
    }

    @Bean
    public RegisteredClientRepository registeredClientRepository() {
        RegisteredClient client = RegisteredClient.withId(UUID.randomUUID().toString())
            .clientId("my-client")
            .clientSecret("{noop}secret")
            .authorizationGrantType(AuthorizationGrantType.AUTHORIZATION_CODE)
            .redirectUri("http://localhost:8081/login/oauth2/code/my-client")
            .scope(OidcScopes.OPENID)
            .build();

        return new InMemoryRegisteredClientRepository(client);
    }

    @Bean
    public JWKSource<SecurityContext> jwkSource() {
        RSAKey rsa = KeyGeneratorUtils.generateRsa();
        JWKSet set = new JWKSet(rsa);
        return (selector, context) -> selector.select(set);
    }

    @Bean
    public AuthorizationServerSettings providerSettings() {
        return AuthorizationServerSettings.builder()
            .issuer("http://localhost:9000")
            .build();
    }
}

Note:
RegisteredClient holds client credentials and grant settings.
JWKSource generates an RSA key pair for signing JWTs.
The issuer URL must match what your resource server expects.

3. Configure the Resource Server

In your API service, add ResourceServerConfig.java:

@Configuration(proxyBeanMethods = false)
public class ResourceServerConfig {

    @Bean
    public SecurityFilterChain resourceSecurityFilterChain(HttpSecurity http) throws Exception {
        http
          .authorizeHttpRequests(auth -> auth
            .requestMatchers("/public/**").permitAll()
            .anyRequest().authenticated()
          )
          .oauth2ResourceServer(oauth2 -> oauth2
            .jwt(jwt -> jwt
              .jwkSetUri("http://localhost:9000/.well-known/jwks.json")
            )
          );
        return http.build();
    }
}

And in application.yml:

spring:
  security:
    oauth2:
      resourceserver:
        jwt:
          jwk-set-uri: http://localhost:9000/.well-known/jwks.json

To enable browser-based login (Authorization Code flow) in a UI module:

spring:
  security:
    oauth2:
      client:
        registration:
          my-client:
            client-id: my-client
            client-secret: secret
            scope: openid
            authorization-grant-type: authorization_code
            redirect-uri: '{baseUrl}/login/oauth2/code/{registrationId}'
        provider:
          my-client:
            issuer-uri: http://localhost:9000

Visiting a protected endpoint will now redirect users to your auth server’s login page.

5. Testing the Flow

Get Authorization Code

http://localhost:9000/oauth2/authorize?
  response_type=code&
  client_id=my-client&
  scope=openid&
  redirect_uri=http://localhost:8081/login/oauth2/code/my-client

Exchange Code for JWT

curl -X POST http://localhost:9000/oauth2/token \
  -u my-client:secret \
  -d grant_type=authorization_code \
  -d code=<AUTH_CODE> \
  -d redirect_uri=http://localhost:8081/login/oauth2/code/my-client

Call Secure API

curl -H "Authorization: Bearer <ACCESS_TOKEN>" \
  http://localhost:8082/api/secure

6. Best Practices

⏱ Short token lifespans (e.g., 15 min) with refresh tokens
🔑 Rotate JWKs regularly
🔐 Always use HTTPS in production
⚙️ Define scopes & claims for fine‑grained access
📊 Monitor token issuance and validation failures

Conclusion

With minimal configuration, you’ve set up a standards‑based, stateless authentication system in Spring Boot. The Authorization Server issues signed JWTs that any Resource Server can validate locally—no session store required. Next steps: add refresh‑token rotation, embed custom claims, or integrate with an identity provider!
